General characteristics
Crew: 2 (Pilot and Radar Intercept Officer)
Length: 62 ft 9 in (19.1 m)
Wingspan:
Spread: 64 ft (19.55 m)
Swept: 38 ft (11.58 m)
Height: 16 ft (4.88 m)
Wing area: 565 ft² (54.5 m²)
Airfoil: NACA 64A209.65 mod root, 64A208.91 mod tip
Empty weight: 43,735 lb (19,838 kg)
Loaded weight: 61,000 lb (27,700 kg)
Max takeoff weight: 74,350 lb (33,720 kg)
Powerplant: 2× General Electric F110-GE-400 afterburning
turbofans
Dry thrust: 13,810 lbf (61.4 kN) each
Thrust with afterburner: 27,800 lbf (123.7 kN) each
Maximum fuel capacity: 16,200 lb internal; 20,000 lb with
2x 267 gallon external tanks
Performance
Maximum speed: Mach 2.34 (1,544 mph, 2,485 km/h) at
high altitude
Combat radius: 500 nmi (575 mi, 926 km)
Ferry range: 1,600 nmi (1,840 mi, 2,960 km)
Service ceiling: 50,000 ft (15,200 m)
Rate of climb: >45,000 ft/min (229 m/s)
Wing loading: 113.4 lb/ft² (553.9 kg/m²)
Thrust/weight: 0.91
Armament
Guns: 1× 20 mm (0.787 in) M61 Vulcan 6-barreled gatling cannon, with
675 rounds
Hardpoints: 10 total: 6× under-fuselage, 2×
under nacelles and 2× on wing gloves with a capacity of
14,500 lb (6,600 kg) of ordnance and fuel tanks
Missiles:
Air-to-air missiles: AIM-54 Phoenix, AIM-7 Sparrow, AIM-9 Sidewinder
Loading configurations:
- 2× AIM-9 + 6× AIM-54 (Rarely used due to weight
stress on airframe)
- 2× AIM-9 + 2× AIM-54 + 3× AIM-7 (Most common
load during Cold War era)
- 2× AIM-9 + 4× AIM-54 + 2× AIM-7
- 2× AIM-9 + 6× AIM-7
- 4× AIM-9 + 4× AIM-54
- 4× AIM-9 + 4× AIM-7
Bombs:
Others:
Avionics
|
|
