General Characteristics:
- Crew: 2 pilots, 1 or more crew chiefs
- Capacity: 37 troops (55 in alternate configuration) or 24
stretchers
- Length: 88 ft 6 in (26.97 m)
- Rotor diameter: 72 ft 2.7 in (22.01 m)
- Height: 24 ft 11 in (7.6 m)
- Empty weight: 23,628 lb (10,740 kg)
- Loaded weight: 33,500 lb (15,227 kg)
- Max takeoff weight: 42,000 lb (19,100 kg)
- Powerplant: 2× General Electric T64-GE-413 turboshaft, 3,925
shp (2,927 kW) each
- Width (stub wings): 28 ft 4 in (8.64 m)
- Width (fuselage): 15 ft 6 in (4.7 m)
- Rotor systems: 6 blades on main rotor
Performance:
- Maximum speed: 170 knots (196 mph, 315 km/h)
- Cruise speed: 150 kt (173 mph, 278 km/h)
- Range: 540 nmi (1,000 km)
- Ferry range: 886 nmi (1,640 km)
- Service ceiling: 16,750 ft (5,106 m)
- Rate of climb: 2,460 ft/min (12.5 m/s)
Armament:
|
|
