General characteristics
Crew: 2
Length: 63.8 ft (19.43 m)
Wingspan: 42.8 ft (13.05 m)
Height: 18.5 ft (5.63 m)
Wing area: 608 ft² (56.5 m²)
Airfoil: NACA 64A006.6 root, NACA 64A203 tip
Empty weight: 31,700 lb (14,300 kg)
Max takeoff weight: 81,000 lb (36,700 kg)
Powerplant: 2× Pratt & Whitney F100-229 afterburning
turbofans, 29,000 lbf (129 kN) each
Performance
Maximum speed: Mach 2.5+ (1,650+ mph, 2,660+ km/h)
Ferry range: 2,400 mi (2,100 nmi, 3,900 km) with conformal
fuel tank and three external fuel tanks
Service ceiling: 60,000 ft (18,200 m)
Rate of climb: 50,000+ ft/min (254+ m/s)
Armament
Guns: 1× 20 mm (0.787 in) M61 Vulcan 6-barreled gatling cannon, 510
rounds of either M-56 or PGU-28 ammunition
Hardpoints:
2 wing pylons, fuselage pylons, bomb racks on CFTs with a capacity
of 23,000 lb (10,400 kg) of external fuel and ordnance
Missiles:
Air-to-air missiles:
Air-to-surface missiles:
Bombs:
Others:
up to 3× 600 US gallons (2,300 L) external drop tanks
for ferry flight or extended range/loitering time.
Avionics
Radar:
Raytheon AN/APG-70
Targeting pods:
LANTIRN
or Lockheed Martin Sniper XR or LITENING targeting pods
Countermeasures:
|
|
