General characteristics

Crew: 2
Length: 63 ft 0 in (19.2 m)
Wingspan: 38 ft 4.5 in (11.7 m)
Height: 16 ft 6 in (5.0 m)
Wing area: 530.0 ft² (49.2 m²)
Airfoil: NACA 0006.4-64 root, NACA 0003-64 tip
Empty weight: 30,328 lb (13,757 kg)
Loaded weight: 41,500 lb (18,825 kg)
Max takeoff weight: 61,795 lb (28,030 kg)
Powerplant: 2 General Electric J79-GE-17A axial compressor turbojets, 17,845 lbf (79.4 kN) each
Zero-lift drag coefficient: 0.0224
Drag area: 11.87 ft² (1.10 m²)
Aspect ratio: 2.77
Fuel capacity: 1,994 U.S. gal (7,549 L) internal, 3,335 U.S. gal (12,627 L) with three external tanks (370 U.S. gal (1,420 L) tanks on the outer wing hardpoints and either a 600 or 610 U.S. gal (2,310 or 2,345 L) tank for the centerline station).
Maximum landing weight: 36,831 lb (16,706 kg)

Performance

Maximum speed: Mach 2.23 (1,472 mph, 2,370 km/h) at 40,000 ft (12,190 m)
Cruise speed: 506 kn (585 mph, 940 km/h)
Combat radius: 367 nmi (422 mi, 680 km)
Ferry range: 1,403 nmi (1,615 mi, 2,600 km) with 3 external fuel tanks
Service ceiling: 60,000 ft (18,300 m)
Rate of climb: 41,300 ft/min (210 m/s)
Wing loading: 78 lb/ft² (383 kg/m²)
lift-to-drag: 8.58
Thrust/weight: 0.86 at loaded weight, 0.58 at MTOW
Takeoff roll: 4,490 ft (1,370 m) at 53,814 lb (24,410 kg)
Landing roll: 3,680 ft (1,120 m) at 36,831 lb (16,706 kg)

Armament

• Up to 18,650 lb (8,480 kg) of weapons on nine external hardpoints, including general purpose bombs, cluster bombs, TV- and laser-guided bombs, rocket pods (UK Phantoms 6 × Matra rocket pods with 18 × SNEB 68 mm rockets each), air-to-ground missiles, anti-runway weapons, anti-ship missiles, targeting pods, reconnaissance pods, and nuclear weapons. Baggage pods and external fuel tanks may also be carried.
• 4× AIM-7 Sparrow in fuselage recesses plus 4 × AIM-9 Sidewinders on wing pylons; upgraded Hellenic F-4E and German F-4F ICE carry AIM-120 AMRAAM, Japanese F-4EJ Kai carry AAM-3, Hellenic F-4E will carry IRIS-T in future. Iranian F-4s could potentially carry Russian and Chinese missiles. UK Phantoms carried Skyflash missiles.
• 1× 20 mm (0.787 in) M61 Vulcan 6-barreled gatling cannon, 640 rounds
• 4× AIM-9 Sidewinder, Python-3 (F-4 Kurnass 2000), IRIS-T (F-4E AUP Hellenic Air Force)
• 4× AIM-7 Sparrow, AAM-3(F-4EJ Kai)
• 4× AIM-120 AMRAAM for F-4F ICE, F-4E AUP (Hellenic Air Force)
• 6× AGM-65 Maverick
• 4× AGM-62 Walleye
• 4× AGM-45 Shrike, AGM-88 HARM, AGM-78 Standard ARM
• 4× GBU-15
• 18× Mk.82, GBU-12
• 5× Mk.84, GBU-10, GBU-14
• 18× CBU-87, CBU-89, CBU-58
