General characteristics:
- Crew: 1
- Length: 37 ft 1 in (11.4 m)
- Wingspan: 37 ft 0 in (11.3 m)
- Height: 14 ft 1 in (4.5 m)
- Wing area: 313.4 sq ft (29.11 m²)
- Empty weight: 11,125 lb (5,046 kg)
- Loaded weight: 15,198 lb (6,894 kg)
- Max takeoff weight: 18,152 lb (8,234 kg)
- Powerplant: 1× General Electric J47-GE-27 turbojet, 5,910
lbf (maximum thrust at 7.950 rpm for five min) (26.3 kN)
- Fuel provisions Internal fuel load: 437 gallons (1,650 l),
Drop tanks: 2 x 200 gallons (756 l) JP-4 fuel
Performance:
- Maximum speed: 687 mph at sea level at 14,212 lb (6,447 kg)
combat weight also reported 678 mph (1,091 km/h) and 599 at 35,000
feet (11,000 m) at 15,352 pounds (6,960 kg). (597 knots, 1,105
km/h at 6446 m, 1,091 and 964 km/h at 6,960 m.)
- Range: 1,525 mi, (1,753 NM, 2,454 km)
- Service ceiling: 49,600 ft at combat weight (15,100 m)
- Rate of climb: 8,100 ft/min at sea level (41 m/s)
- Thrust/weight: 0.38
- Stalling speed (power off): 124 mph (108 kt, 200 km/h)
- Landing ground roll: 2,330 ft, (710 m)
- Lift-to-drag ratio: 15.1
- Time to altitude: 5.2 min (clean) to 30,000 ft (9,100 m)
Armament:
- Guns: 6 × 0.50 in (12.7 mm) M2 Browning machine guns (1,602 rounds in
total)
- Rockets: variety of rocket launchers; e.g: 2 × Matra
rocket pods with 18× SNEB 68 mm rockets each
- Missiles: 2× AIM-9 Sidewinders
- Bombs: 5,300 lb (2,400 kg) of payload on four external hardpoints,
bombs are usually mounted on outer two pylons as the inner pairs
are wet-plumbed pylons for 2 × 200 gallons drop tanks to
give the Sabre a useful range. A wide variety of bombs can be
carried (max standard loadout being 2 × 1,000 lb bombs
plus 2 drop tanks), napalm bomb canisters and can include a tactical
nuclear weapon.
|
|
